| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 10/250 in/mm |
| MAX Power | 600 Watts |
| RMS Power | 300 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 60 Hz |
| Frequency Response | 60-4500 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 3''/75mm |
| Voice Coil Material | GSV(inside-outside) |
| Magnet | 80OZ |
| THIELE & SMALL PARAMETERS | |
| FS | 60 Hz |
| RE | 5.4 ohm |
| Qms | 12 |
| Qes | 0.35 |
| Qts | 0.34 |
| BL | 16T/m |
| MMS | 44 grams |
| Xmax | 6.5 mm |
| Sd | 363 cm² |
| Efficiency | 1.6% |
| Le(1k Hz) | 0.2mH |
| EBP | 161 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 10.45/265 in/mm |
| Bolt Circle Diameter | 10/250 in/mm |
| Baffle cutout Diameter | 9.29 /237 in/mm |
| Depth | 5.5 /140 in/mm |
| Net Weight | 6.85 kgs |
| Shipping Weight | 7.85 kgs |
| Shipping Box | 28X28X16cm |
