| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 15/385 in/mm |
| MAX Power | 1600 Watts |
| RMS Power | 800 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 32 Hz |
| Frequency Response | 32-2000 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4"/100mm |
| Windling material | GEI(inside-outside) |
| Magnet | 125 Oz 220*110*25mm |
| MOUNTING/SHIPPING INFORMATION | ||
| Overall Diameter | 15.5/395 | in/mm |
| Bolt Circle Diameter | 14.7/375 | in/mm |
| Baffle cutout Diameter | 14.1/360 | in/mm |
| Depth | 7.3/185 | in/mm |
| Net Weight | 11. 75 kgs | |
| Shipping Weight | 12.15 kgs | |
| Shipping Box | 41X41X20cm | |
| THIELE SMALL PARAMETERS | |
| FS Hz | 32 Hz |
| Vas | 204 dm³ |
| RE Ohms | 6. 2ohm |
| Qms | 1 |
| Qes | 0. 21 |
| Qts | 0. 20 |
| BLT/m | 26 T/m |
| MMS(grms) | 123 grams |
| Xmax(mm) | 4. 4 mm |
| Sd | 850 cm² |
| Efficiency % | 3% |
| EBP | 152 |
