| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 6. 7/170 in/mm |
| Depth | 2. 6/66 in/mm |
| Net Weight | 4.55 kgs |
| Shipping Weight(1 pc) | 4. 6 kgs |
| Shipping Box(1 pc) | 18X18X7.5cm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 1.5/38 in/mm |
| MAX Power | 240 Watts |
| RMS Power | 120 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 800 Hz-20k Hz |
| Sensitivity(1W/1m) | 112 dB |
| Voice Coil Diameter | 3"/74.4mm |
| Windling material | CCAR |
| Magnet | 62 Oz |
| Diaphragm material | Titanium diaphragm |
