TN-DE680TN

TN-DE680TN

HF Drivers - Neodymium

80

Watts RMS

1khz-18khz

Response

108dB

Sensitivity

Nominal impedance

MOUNTING/SHIPPING INFORMATION
Overall Diameter 1.5/115   in/mm
Depth 2/50    in/mm
Net Weight 1. 65 kgs
Shipping Weight(1 pc) 1. 7 kgs
Shipping Box(1 pc) 11. 8X11.8X8. 6cm
ELECTRO ACOUSTIC SPECIFICATIONS
Throat Diameter 1.5/38  in/mm
MAX Power 160 Watts
RMS Power 80  Watts
Impedance 8 Ohm
Frequency Response 1K Hz-18k Hz
Sensitivity(1W/1m) 108 dB
Voice Coil Diameter 2.5"/65mm
Windling material CCAR
Magnet Neodymium
Diaphragm material Titanium  diaphragm
