MOUNTING/SHIPPING INFORMATION | |
Overall Diameter | 4. 6/116 in/mm |
Depth | 2. 7/69 in/mm |
Net Weight | 1. 2 kgs |
Shipping Weight(1 pc) | 1. 3 kgs |
Shipping Box(1 pc) | 12. 5X12. 5X7. 5 cm |
MOUNTING/SHIPPING INFORMATION | |
Overall Diameter | 4. 6/116 in/mm |
Depth | 2. 7/69 in/mm |
Net Weight | 1. 2 kgs |
Shipping Weight(1 pc) | 1. 3 kgs |
Shipping Box(1 pc) | 12. 5X12. 5X7. 5 cm |
ELECTRO ACOUSTIC SPECIFICATIONS | |
Throat Diameter | 1./25 in/mm |
MAX Power | 120 Watts |
RMS Power | 60 Watts |
Impedance | 8 Ohm |
Frequency Response | 1K Hz-20k Hz |
Sensitivity(1W/1m) | 106 dB |
Voice Coil Diameter | 1. 75"/44.4mm |
Windling material | CCAW |
Magnet | Neodymium |
Diaphragm material | Titanium diaphragm |
