MOUNTING/SHIPPING INFORMATION | |
Overall Diameter | 4.3/110 in/mm |
Depth | 2.4/60 in/mm |
Net Weight | 1 kgs |
Shipping Weight(1 pc) | 1. 2 kgs |
Shipping Box(1 pc) | 11. 8X11. 8X7. 5cm |
ELECTRO ACOUSTIC SPECIFICATIONS | |
Throat Diameter | 1/25 in/mm |
MAX Power | 120 Watts |
RMS Power | 60 Watts |
Impedance | 8 Ohm |
Frequency Response | 1K Hz-20k Hz |
Sensitivity(1W/1m) | 107dB |
Voice Coil Diameter | 1. 75"/44.4mm |
Windling material | CCAW |
Magnet | Neodymium |
Diaphragm material | Titanium diaphragm |
