TN-NX5210

TN-NX5210

HF Drivers - Neodymium

80

Watts RMS

1KHZ-20KHZ

Response

108dB

Sensitivity

Nominal impedance

MOUNTING/SHIPPING INFORMATION
Overall Diameter 4.4/112   in/mm
Depth 2.0/50     in/mm
Net Weight 1.4 kg
Shipping Weight(1 pc) 1. 5 kg
Shipping Box(1 pc) 12. 5X12.5X6. 5 cm
ELECTRO ACOUSTIC SPECIFICATIONS
Throat Diameter 1.5/38  in/mm
MAX Power 160 Watts
RMS Power 80  Watts
Impedance 8 Ohm
Frequency Response 1K Hz-20k Hz
Sensitivity(1W/1m) 108 dB
Voice Coil Diameter 2"/51. 6mm
Windling material CCAW
Magnet Neodymium
Diaphragm material Titanium diaphragm
